CREST
Center Basket Troffer LED
Ascent Architectural Lighting
CREST is a versatile center-basket LED troffer that delivers uniform, glare-free illumination with selectable wattages and five adjustable color temperatures (3500K–6500K). Featuring a sleek, low-profile design and back-lit frosted polycarbonate lens, it offers up to 6,500 lumens at an impressive 125 LPW. CREST is manufactured with a single stamping process producing corners and sides that are turned in and hemmed which removes sharp edges for safer installation. Compatible with standard t-grid ceilings and 0–10V dimming systems, CREST is ideal for schools, offices, and healthcare settings. DLC Premium listed and backed by a 5-year warranty, it’s engineered for performance, efficiency, and flexibility.
Additional Downloads
Physical
- Material: Aluminum & Steel
- Mounting: Recessed T-Grid Compatible with 9/16" Flat, 9/16" Slot, 9/16" Interlude and 15/16" Flat
- Finish: White
Electrical
- Wattage: Field Selectable 2x2: 15W, 20W, 25W, 30W, 40W; 2x4: 25W, 30W, 35W, 40W, 50
- Voltage: 110-277V
- Dimmable: 10-100% 0-10V
Performance
- CCT: Field Selectable: 3500K, 4000K, 5000K, 5700K, 6500K
- CRI: 80CRI
- Operating Temperature: -20°C - 40°C ( -4 - 113°F )
Approvals
- cETLus
- Damp Location
- DLC Premium
