Illuminated Mirror LED

The RAM features a silver-backed mirror set within a slim aluminum frame, with an iron back plate for rigidity and an aluminum keyhole mounting system for secure, flush wall installation. The mirror surface incorporates a frosted lighting channel along the perimeter, which diffuses the integrated LED source for even, glare-free edge illumination, along with an anti-fog element sized to the mirror to help maintain clarity in humid conditions. The frame is available in eight finishes — Black, Brown, Chrome, Coffee, Gold, Satin Nickel, Silver, and White — and the fixture carries an IP44 ingress protection rating, making it suitable for bathroom and other moisture-prone installations. Wire entry is made through a chassis knockout, simplifying connection to a junction box or in-wall wiring during installation.

The RAM operates on 120V and is rated with a 0.6 power factor. Depending on size and CCT configuration, the fixture draws between approximately 56 and 151 total watts (LED light plus anti-fog element combined), delivering between roughly 900 and 2,600 lumens at a consistent efficacy of 80 lm/W across the range. Color temperature is available as a single fixed setting from 2700K to 6000K, as a field-selectable three-CCT option (3000K/3500K/4000K), or as a tunable white configuration spanning 3000K–6000K, with field-selectable and tunable white modes controlled via touch button. CRI is 80+. The fixture is dimmable via hard wire (ELV or 0–10V) or touch button, and is also available with push-button on/off or microwave occupancy sensor on/off control.

Part of the RAM family: The RAM Illuminated Mirror LED is available in eight standard sizes, from 24" x 32" up to 40" x 40", with custom sizes available upon request. This range allows the RAM to scale from a single-vanity powder room to a wide double-vanity primary bath while maintaining the same frameless aesthetic and edge-lit performance throughout the project.

Choosing a color temperature: The RAM's illumination can be specified three ways: a fixed single CCT for projects with a defined lighting temperature, a field-selectable three-CCT option (3000K, 3500K, or 4000K) for flexibility on site, or a tunable white configuration spanning 3000K to 6000K for full-range control via touch button. Fixed single-CCT options span warm 2700K through cool 6000K, so specifiers working with an established lighting plan can match the RAM to adjacent fixtures, while field-selectable and tunable white configurations suit projects where the ideal color temperature may be adjusted after installation.

Control options: The RAM supports several control methods to match a project's electrical scope: hard-wire ELV dimming and hard-wire 0–10V dimming for integration with existing dimming systems, touch-button dimming for a clean, switch-free vanity, push-button on/off for simple operation, and microwave occupancy sensor on/off for hands-free, energy-conscious control in guest baths or public restrooms. Confirm control compatibility with the project's dimming or control infrastructure prior to specification.

Moisture resistance for bath and vanity settings: With an IP44 ingress protection rating, the RAM is built to withstand the splashing and humidity typical of bathroom and vanity environments. The integrated anti-fog element further supports reliable visibility immediately after showering, making the RAM a practical choice for primary baths, guest baths, and hospitality restrooms alike.

Finish selection: The RAM's eight finish options — Black, Brown, Chrome, Coffee, Gold, Satin Nickel, Silver, and White — span both warm and cool metal tones as well as classic neutrals, allowing the frame to coordinate with cabinetry hardware, plumbing fixtures, and other decorative lighting in the space.

Ordering logic: Use the format RAM-[Size]-[CCT]-[Finish]-[Control Options]. Example: RAM-2436-27-BK specifies the RAM Illuminated Mirror at 24" x 36" with 2700K color temperature in a Black finish. Add the appropriate control option code — HWELV, HW010, TB, PB, or OS — to specify the desired dimming or on/off control method.
