SL8LSL8L
Step Light 8" Louver LED
Terrain
SL8L is a 120-277V 8" LED louvered step light ideal for new construction applications where low level glare free path lighting is desired. SL8L is supplied with an aluminum faceplate and field selectable CCT. The plastic junction box is the size of a standard brick (8.54"W x 3.23"H x 2.23"D) with conduit knockouts on both sides for easy installation. SL8L is IP65 rated, wet location listed and available in multiple finishes.
SL8L is a 120-277V 8" LED louvered step light ideal for new construction applications where low level glare free path lighting is desired. SL8L is supplied with an aluminum faceplate and field selectable CCT. The plastic junction box is the size of a standard brick (8.54"W x 3.23"H x 2.23"D) with conduit knockouts on both sides for easy installation. SL8L is IP65 rated, wet location listed and available in multiple finishes.
Beam Angle
- 30
CCT
- 2700K
- 3000K
- 4000K
CRI
- 90
Color / Finish
- Bronze
- Satin Nickel
Dimensions
- L: 8.67 In. W: 3.32 In. H: 3.39 In.
Dimming Protocol
- Triac (Leading Edge)
Efficacy
- 11
- 22
Lamp Life
- 50000
Lamp Source
- LED
Listings
- cETLus
Lumens
- 50
- 100
Materials
- Aluminum
- Plastic
Ratings & Compliance
- IP65
- Wet
Shape
- Rectangular
Static LED Color
- White
Voltage
- 120 V
- 120-277 V
- 208 V
- 220 V
- 230 V
- 240 V
- 277 V
- MVOLT
Warranty
- 3 yr
Watts
- 4.5
