Summit 23Summit 23
Architectural Linear LED
Ascent Architectural Lighting
Summit is a sleek, streamlined architectural linear LED luminaire combining modern aesthetics with exceptional lighting quality. Summit 23 has a 2.34" wide profile that can be pendant, surface, or wall mounted in a black or white finish. Summit 23 can adapt to any application with 2ft, 4ft, or 8ft lengths that are equipped with field selectable CCT and field selectable wattage. The pendant version includes field selectable distribution offering 7 optical options for direct, indirect, and direct/indirect lighting.
Summit is a sleek, streamlined architectural linear LED luminaire combining modern aesthetics with exceptional lighting quality. Summit 23 has a 2.34" wide profile that can be pendant, surface, or wall mounted in a black or white finish. Summit 23 can adapt to any application with 2ft, 4ft, or 8ft lengths that are equipped with field selectable CCT and field selectable wattage. The pendant version includes field selectable distribution offering 7 optical options for direct, indirect, and direct/indirect lighting.
Availability
- Quick Ship | Call for Stock
CCT
- 3000K
- 3500K
- 4000K
CRI
- 80 CRI
- 90 CRI
Color / Finish
- Black
- White
Controls Options
- Occupancy Sensor
Data Integrity
- Low
Dimensions
- H: 3.46 In. L: 23.7 In. W: 2.34 In.
- H: 3.46 In. L: 47.72 In. W: 2.34 In.
- H: 3.46 In. L: 35.71 In. W: 2.34 In.
- H: 3.46 In. L: 95.24 In. W: 2.34 In.
Dimming Protocol
- 0-10 V
Dimming Range
- 1%
- 10%
Distribution
- Direct
Efficacy
- 115 lm/w
Emergency Options
- Emergency Battery Backup
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- UL
- cULus
Lumens
- 950 Lm
- 1100 Lm
- 1150 Lm
- 1200 Lm
Materials
- Aluminum
Mounting
- Ceiling
- Grid
- Pendant
- Surface
- Wall
Product Priority
- Key
Ratings & Compliance
- Damp
- Dry
Static LED Color
- White
Voltage
- 120 V
- 120-277 V
- 277 V
Warranty
- 5 yr
Watts
- 10 w
- 15 w
- 20 w
- 23 w
- 30 w
- 40 w
- 60 w
- 80 w
